Features
- Light weight construction
- LSmooth operations
- PU Wheel
- Safe to use
- Attractive, sleek and robust design
|
|
| |
Specifications |
| |
| Model |
|
|
SAPS-6 |
SAPS-8 |
SAPS-10 |
| Max. Platform height |
|
mm |
6000 |
8000 |
10000 |
| Rated capacity |
|
kg |
150 |
125 |
125 |
| Ground clearance |
|
mm |
|
80 |
|
| Platform size (L x W) |
|
mm |
|
650x600 |
|
| |
AC |
v |
|
220 |
|
| Electric Power |
DC |
v |
|
24 |
|
| |
AC |
v/kw |
|
220/0.75 |
|
| Lifting Motor |
DC |
v/kw |
|
24/2.0 |
|
| Machine size (L x W x H) |
|
mm |
1330x800x1950 |
1330x800x2050 |
1330x800x2150 |
| |
AC |
kg |
300 |
350 |
400 |
| Net weight |
DC |
kg |
332 |
382 |
432 |
|
|
| |
|
 |
